BRTV17WSS5PC series applies to all types of horizontal injection machine ranges of 600T-1300T for take-out products and sprue. The installation is different from traditional beam robots, products are placed at the end of injection molding machines, which can save installation space for the ejection machine. Arm form: telescopic type and single arm, five axis AC servo drive, with AC servo drive axis, A axis rotation angle of 360°, C axis rotation angle of 180°, can freely position and adjust fixture angle, long service life, high accuracy, low failure rate, simple maintenance, mainly used for quick removal or complex angle removal applications, especially for long shaped products such as automotive products, washing machines and household appliances. Five-axis driver and controller integrated system: fewer signal lines, long-distance communication, good expansion performance, strong anti-interference ability, high accuracy of repeated positioning, can simultaneously control multiple axes, simple equipment maintenance, and low failure rate.

MainSpecification:

Model representation: W：Telescopic type. D：Product arm + runner arm. S5:Five-axis driven by AC Servo Motor(Traverse-axis、Vertical-axis+Crosswise-axis).

The above-mentioned cycle time are the results of our company’s internal test standard. In the actual application process of the machine, they will vary according to the actual operation.
