¥300000
No further notice if the specification and appearance are changed due to improvement and other reasons. Thank you for your understanding.
BRTIRUS2830B is a six axis robot developed by BORUNTE for complex applications with multiple degrees of freedom. Its maximum load can reach 300kg, with a 2832mm arm span and six degrees of freedom of flexibility, making it capable of handling scenarios such as loading and unloading, assembly, and transportation of injection molded parts on the machine tool. The protection grade reaches IP40. The repeat positioning accuracy is ±0.2mm.
MainSpecification:
Arm Length(mm)：2832
Repeatability(mm)：±0.2
Loading Ability(kg)：300
Power Source(kVA)：15.62
Weight(kg)：1976
|
Item |
Range |
Max.speed |
|
|
Arm |
J1 | ±160° | 71.3°/s |
| J2 | -85°/+55° |
74.2°/s |
|
|
J3 |
-60°/+105° | 102.3°/s | |
| Wrist | J4 | ±180° |
122.7°/s |
|
J5 |
±130° | 71.1°/s | |
| J6 | ±360° |
116.3°/s |
|
If you are interested in buying the robots or inquiring about the robot applications, or you want to cooperate with BORUNTE,feel free to contact us. We will provide the best solution for your needs.
