BRTIRUS1820A is a six-axis robot developed by BORUNTE for complex applications with multiple degrees of freedom. The maximum load is 20kg, the maximum arm length is 1850mm. Lightweight arm design, compact and simple mechanical structure, in the state of high speed movement, can be carried out in a small workspace flexible work, meet the needs of flexible production. It has six degrees of flexibility.Suitable for loading and unloading, injection machine, die casting, assembling, coating industry, polishing, detection etc.It is suitable for injection molding machine range from 500T-1300T. The protection grade reaches IP54 at the wrist and IP40 at the body. The repeat positioning accuracy is ±0.05mm.

MainSpecification:

Arm Length(mm)：1850

Repeatability(mm)：±0.05

Loading Ability(kg)：20

Power Source(kVA)：5.87

Weight(kg)：Approx.230
