BRTIRUS0401A type robot is a six-axis robot that designed by BORUNTE for the operation environment of micro and small parts. It is suitable for small parts assembly, sorting, detection and other operations. The rated load is 1kg, the arm span is 465mm, and it has the highest level of operation speed and a wide range of operation among six-axis robots with the same load. It features high precision, high speed and high flexibility. The protection grade reaches IP54. Dust-proof and water-proof. The repeat positioning accuracy is ±0.06mm.

MainSpecification:

Arm Length(mm)：465

Repeatability(mm)：±0.06

Loading Ability(kg)：1

Power Source(kVA)：2.03

Weight(kg)：Approx.21
