BRTIRPZ3013A type robot is a four-axis robot that developed by BORUNTE for some monotonous, frequent and repetitive long-term operations or operations in dangerous and harsh environments. The maximum arm length is 3020mm. The maximum load is 130kg.It’s flexible with multiple degrees of freedom. Suitable for loading and unloading, handling,dismantling and stacking etc. The protection grade reaches IP40. The repeat positioning accuracy is ±0.15mm.

MainSpecification:

Arm Length(mm)：3020

Repeatability(mm)：±0.15

Loading Ability(kg)：130

Power Source(kVA)：8.23

Weight(kg)：About1200
